Azon Q PRO & PRO L
UV
A1+ en B0 modellen met maximaal 20 cm substraat hoogte!
- Maximaal pringebied is 118cm x 245cm x 20cm (breedte x lengte x hoogte)
- Maximale resolutie 1440dpi
| Model | Azon Q PRO & PRO L UV |
| Print techniek | Inkjet Piezo (180 nozzles per kanaal) |
| Print gebied | maximaal 59cm x 120cm x 20cm Q PRO (breedte x lengte x hoogte) |
| maximaal 110cm x 250cm x 20cm Q PRO L (breedte x lengte x hoogte) | |
| Maximaal substraat gewicht | 20kg |
| Inkt cartridges | CMYK en wit. Optioneel met gloss of primer te configureren |
| Azon UV inkt, in gesloten, ontluchtte en onder druk gevulde cartridges | |
| 220cc per cartridge | |
| Inkt uitharding | UV LED lamp |
| Print resolutie | Maximaal 1440 x 1440 dpi, geoptimaliseerd |
| Energie verbruik | 156W, standby 16,7W |
| Aansluitspanning | AC 100 tot 240V ± 10%, 1,8A, 50/60Hz |
| Geluidsniveau | 60dB(A) of minder tijdens gebruik |
| Connectiviteit | USB 2.0, 100Base-T Ethernet |
| Omgevings variabele | 200 tot 300C, 35 tot 80% RH |
| Afmetingen | 1800mm x 1000mm x 1500mm Q PRO (breedte x lengte x hoogte) |
| 3500mm x 1800mm x 1200mm Q PRO L (breedte x lengte x hoogte) | |
| Gewicht | 350kg Q PRO |
| 710kg Q PRO L | |
| Aansturing | Azon JetRIP |
| Windows7(32 & 64bit), Vista(32 & 64bit), Windows XP((32 & 64bit) |
Alle specificaties kunnen zonder voorafgaande kennisgeving worden gewijzigd
